General Information
1-6
BE3-GPR
Curve Curve BE Curve Name Trip Characteristic Constants
Number Selection A B C N K
17 F Fixed Time 0.0000 1.00000 0.000 0.0000 0.028
Impulse
Qualified to IEC 255-5
Radio Frequency Interference
(RFI)
Field tested using a 5 watt, hand held transceiver operating at random
frequencies centered around 144 Mhz and 440 Mhz, with the antenna
located 6 inches from the relay in both horizontal and vertical planes.
Surge Withstand Capability:
Oscillatory
Fast transient
Qualified to IEEE C37.90.1-1989 Standard Surge Withstand Capability
(SWC) Tests for Protective Relays and Relay Systems
Qualified to IEEE C37.90.1-1989 Standard Surge Withstand Capability
(SWC) Tests for Protective Relays and Relay Systems
Vibration: 10 to 500 Hz at 2 Gs in three mutually perpendicular planes.
Shock: 15 Gs in each of three mutually perpendicular axes.
Temperature:
Operating Range:
Storage Range:
-25
°
C (-13
°
F) to +60
°
C (+140
°
F)
-40
°
C (-40
°
F) to +85
°
C (+185
°
F)
Weight: 4 lb.
STYLE CHART
BE3-GPR relays are identified by a combination of letters and numbers that make up the style number
and define the electrical characteristics and operational features. The model number, together with the
style number, describe the options included in a specific device and appear on a relay side panel.
Upon receipt of a relay, be sure to check the style number against the requisition and the packing list to
ensure that they agree.
Figure 1-2 is the style number identification chart and defines the electrical characteristics and operational
features included in BE3-GPR relays. In this example, a BE3-GPR P2BVSF is specified and has the
following features:
P - Paralleled generator protection
2 - Neutral ground fault protection
B- Phase balance
V - Reactive current
S - Sync check function
F - Semi-flush mounting
