General Information 1-7
BE3-GPR
S - STAND ALONE
P - PARALLELED GEN
1 - 3-PHASE OVERCURRENT
2 - NEUTRAL GROUND FAULT
N - NO PHASE BALANCE
B - PHASE BALANCE
V - REACTIVE CURRENT
S - SYNC-CHECK
MODEL TYPE
OPTION 1
OPTION 2
OPTION 4
OPTION 3
0 - NO REACTIVE CURRENT
N - NO SYNC-CHECK
*
*
P2B VS
PHASE BALANCE
REACTIVE CURRENT
SYNC-CHECK
NOTE: * Paralleled models only.
D2224-13
08-04-98
OVERCURRENT TYPE
F
CONFIGURATION
F - SEMI-FLUSH
B - BEHIND-THE-PANEL
MOUNTING
Figure 1-2. BE3-GPR Style Chart
TIME OVERCURRENT CHARACTERISTIC CURVES
Figures 1-2 through 1-17 illustrate the characteristic curves that are programmed into the nonvolatile
memory of this relay. A drawing number is given under each caption and listed in Table 1-2. Table 1-2
also cross references the BE3-GPR curves to existing electromechanical relay characteristics. Contact
Customer Service Department of the Power Systems Group, Basler Electric, and request the drawing
number to order a full-size (10 inch x 12 inch) Characteristic Curve graph on transparent paper (vellum).
Table 1-2. Characteristic Curve Cross Reference
Curve
Number
BE3-GPR
Curve
Curve Name Drawing NO. Similar To
1 S1 S1, Short Inverse 99-1369 ABB CO-2
2 S2 S2, Short Inverse 99-1595 GE IAC-55
3 L1 L1, Long Inverse 99-1370 ABB CO-5
4 L2 L2, Long Inverse 99-1594 GE IAC-66
5 D D, Definite Time 99-1371 ABB CO-6
6 M M, Moderately Inverse 99-1372 ABB CO-7
7 I1 I1, Inverse Time 99-1373 ABB CO-8
8 I2 I2, Inverse Time 99-1597 GE IAC-51
9 V1 V1, Very Inverse 99-1374 ABB CO-9
10 V2 V2, Very Inverse 99-1596 GE IAC-53
11 E1 E1, Extremely Inverse 99-1375 ABB CO-11
12 E2 E2, Extremely Inverse 99-1598 GE IAC-77
13 A Standard Inverse 99-1621 BS, IEC Standard Inverse
14 B B, Very Inverse (It) 99-1376 BS, IEC Very Inverse (It)
15 C Extremely Inverse (I
2
t) 99-1377 BS, IEC Extremely Inverse (I
2
t)
16 G Long Time Inverse 99-1622 BS, IEC Long Time Inverse
17 F Fixed Time
