Basler BE3-GPR User Manual

Functional Description
3-14
Table 3-1. Available Commands
Command Description
VV = d1
d1 = software version identification number
(For Basler Electric Company use only)
CFG
(System
Configuration)
CFG = d1, d2, d3
d1 = auto reset: 0 (disabled) or 1(enabled)
d2 = CT Configuration: 1 (1A CT) or 5 (5A CT)
d3 = generator voltage sensing:
1 (single phase line-to-line)
3 (three phase line-to-line)
4 (three phase line-to-neutral)
OV
(Overvoltage)
OV = d1, d2, d3, d4
d1 = over voltage trip enable: 0 (disable) or 1 (enable)
d2 = over voltage trip level (volts)
d3 = over voltage reset level (volts)
d4 = over voltage time delay (seconds)
UV
(Undervoltage)
UV = d1, d2, d3, d4
d1 = under voltage trip enable: 0 (disable) or 1 (enable)
d2 = under voltage trip level (volts)
d3 = under voltage reset level (volts)
d4 = under voltage time delay (seconds)
OF
(Overfrequency)
OF = d1, d2, d3, d4
d1 = over frequency trip enable: 0 (disable) or 1 (enable)
d2 = over frequency trip level (Hertz * 10)
d3 = over frequency reset level (Hertz * 10)
d4 = over frequency time delay (seconds)
UF1
(Underfrequency)
UF1 = d1, d2, d3, d4
d1 = under frequency 1 trip enable: 0 (disable) or 1 (enable)
d2 = under frequency 1 trip level (Hertz * 10)
d3 = under frequency 1 reset level (Hertz * 10)
d4 = under frequency 1 time delay (seconds)
UF2
(Underfrequency)
UF2 = d1, d2, d3, d4
d1 = under frequency 2 trip enable: 0 (disable) or 1 (enable)
d2 = under frequency 2 trip level (Hertz * 10)
d3 = under frequency 2 reset level (Hertz * 10)
d4 = under frequency 2 time delay (seconds)
NGF
(Neutral Ground
Fault)
NGF = d1, d2, d3, d4
d1 = neutral ground fault trip enable: 0 (disable) or 1 (enable)
d2 = neutral ground fault trip level (Amps * 100)
d3 = neutral ground fault reset level (Amps * 100)
d4 = neutral ground fault time delay (seconds * 10)
