Basler DECS-150 User Manual

18-10 9492600990
BESTCOMSPlus
®
Software DECS-150
Printing a Settings File
To view a preview of the settings printout, select Print from the File pull-down menu. To print the settings,
select the printer icon in the upper left corner of the Print Preview screen.
Comparing Settings Files
BESTCOMSPlus has the ability to compare two settings files. To compare files, pull down the Tools menu
and select Compare Settings Files. The BESTCOMSPlus Settings Compare Setup dialog box appears
(Figure 18-7). Select the location of the first file under Left Settings Source and select the location of the
second file under Right Settings Source. If you are comparing a settings file located on your PC hard
drive or portable media, click the folder button and navigate to the file. If you want to compare settings
downloaded from a unit, click the Select Unit button to set up the communication port. Click the Compare
button to compare the selected settings files.
Figure 18-7. BESTCOMSPlus Settings Compare Setup
A dialog box will appear and notify you if any differences were found. The BESTCOMSPlus Settings
Compare dialog box (Figure 18-8) is displayed where you can view all settings (Show All Settings), view
only the differences (Show Settings Differences), view all logic (Show All Logic Paths), or view only logic
differences (Show Logic Path Differences). Select Close when finished.
Figure 18-8. BESTCOMSPlus
®
Settings Compare
