AW00118508000 Features
Basler racer Camera Link 101
If you change the clock speed while the camera is in the process of acquiring images:
Triggering and image acquisition will stop.
Any acquired image that is being transmitted will be delivered.
The camera’s clock speed will be changed internally.
Once the change is complete, triggering and image acquisition will resume.
The Camera Link clock speed setting will be stored in the camera’s configuration sets. This means,
for example, that if you have a different clock speed setting stored in user set 1 and user set 2 and
you change the active set from user set 1 to user set 2, the clock speed will change.
For more information about the maximum allowed line acquisition rate, see Section 6.4 on page 87.
For more information about configuration sets, see Section 8.14 on page 143.
Setting the Camera Link Pixel Clock
You can use the pylon API to set the Camera Link pixel clock speed from within your application
software. The following code snippet illustrates using the API to set the clock speed:
// Set the Camera Link pixel clock speed 32.5
camera.ClPixelClock.SetValue(ClPixelClock_PixelClock32_5);
// Set the Camera Link pixel clock speed to 48
camera.ClPixelClock.SetValue(ClPixelClock_PixelClock48);
You can also use the Basler pylon Viewer application to easily set the parameters.
For more information about the pylon API and the pylon Viewer, see Section 3.1 on page 26.
Set the value of the Cl Pixel Clock register for 32.5, 48, 65, or 83.5 MHz.
For more information about changing settings via direct register access, see Section 3.2 on
page 28.
You can use the pylon API to set the pixel clock speed to 32.5, 48, 65, or
83.5 MHz. These are the only valid values for the pixel clock speed. If you attempt
to use the API to set the clock speed to a value other then these, the camera will
automatically round the setting down to the nearest valid speed.
To set the Camera Link pixel clock speed via direct register access:
