AW00118508000 Features
Basler racer Camera Link 134
8.10 Error Detection
8.10.1 LED Indicator
The LED indicator on the back of the camera includes both a small red LED and a small green LED.
The LED indicator signals the camera’s current condition as shown in Table 20.
LED State Status Indication
Red and Green Both Off No power to the camera
Continuous Green The camera has booted up successfully and is OK.
Flashing Green The camera is set to expect a hardware trigger signal on an input, but no
trigger signal is present.
Green and Red Both Flashing
Alternately
An error condition has been detected that may be correctable with user
intervention. (See Section 8.10.2 on page 135 for more information).
Flashing Red Internal error. Contact Basler technical support.
Table 20: LED Indications
During the camera bootup process, the red and the green LED will simultaneously
be lit.
