AW00118508000 Specifications, Requirements, and Precautions
Basler racer Camera Link 18
1.8 Mechanical Stress Test Results
racer cameras were submitted to an independent mechanical testing laboratory and subjected to
the stress tests listed below. The mechanical stress tests were performed on selected camera
models with standard housing. After mechanical testing, the cameras exhibited no detectable
physical damage and produced normal images during standard operational testing.
Test Standard Conditions
Vibration
(sinusoidal, each axis)
DIN EN 60068-2-6 10-58 Hz / 1.5 mm_58-500 Hz / 20 g_1 Octave/Minute
10 repetitions
Shock (each axis)
DIN EN 60068-2-27 20 g / 11 ms / 100 shocks positive
20 g / 11 ms / 100 shocks negative
Vibration
(broad-band random,
digital control, each axis)
DIN EN 60068-2-64 15-500 Hz / 0.05 PSD (ESS standard profile) / 00:30 h
Table 5: Mechanical Stress Tests
