Basler racer User Manual

AW00118508000 Physical Interface
Basler racer Camera Link 45
 For the CC1 line, set the value of the Input Debouncer Time CC1 register as desired (the value
represents milliseconds).
 For the CC2 line, set the value of the Input Debouncer Time CC2 register.
 For the CC3 line, set the value of the Input Debouncer Time CC3 register.
 For the CC4 line, set the value of the Input Debouncer Time CC4 register.
For more information about direct register access, see Section 3.2 on page 28.
5.5.1.2 Input Line Inverters
You can set CC1, CC2, CC3, and the CC4 line to invert or not to invert the input signal.
1. Set the LineSelector parameter to CC1, CC2, CC3, or CC4.
2. Set the LineInverter parameter to True to enable inversion on the selected line or to False to
disable inversion.
You can set the LineSelector and the LineInverter parameter values from within your application
software by using the pylon API. The following code snippet illustrates using the API to set the
parameter values:
// Select the CC1 line
camera.LineSelector.SetValue(LineSelector_CC1);
// Disable the inverter on the selected line
camera.LineInverter.SetValue(false);
You can also use the Basler pylon Viewer application to easily set the parameters.
For more information about the pylon API and the pylon Viewer, see Section 3.1 on page 26.
 For the CC1 line, set the value of the Line Inverter CC1 register to 0 (false) or 1 (true) as
desired.
 For the CC2 line, set the value of the Line Inverter CC2 register.
 For the CC3 line, set the value of the Line Inverter CC3 register.
 For the CC4 line, set the value of the Line Inverter CC4 register.
For more information about direct register access, see Section 3.2 on page 28.
To set the debouncer via direct register access:
To set the invert function on an input line using Basler pylon:
To set the invert function on an input line via direct register access:
