AW00118508000 Physical Interface
Basler racer Camera Link 35
5.2.2 26-pin SDR Connectors
Two 26-pin, 0.03” pin spacing, Shrunk Delta Ribbon (SDR) female connectors are used to transmit
video data, control signals, and configuration commands.
The base Camera Link SDR connector can also be used to supply power to the cameras in
accordance with the Power over Camera Link (PoCL) specifications in the Camera Link standard.
Note that only the 2k and 4k cameras can be fully operated using PoCL. For more information about
correctly supplying power for full camera operation, see Section 5.4.3 on page 42.
The pin assignments and pin numbering are shown in Table 7 on page 36 for the base Camera Link
SDR connector and in Table 8 on page 37 for the medium/full Camera Link SDR connector.
A suitable cable is available from Basler. See the Basler website for information about cable
characteristics. For voltage requirements of camera power, see Section 5.4 on page 40.
