AW00118508000 Features
Basler racer Camera Link 135
8.10.2 Error Codes
The camera can detect several user correctable errors. If one of these errors is present, the camera
will set an error code and will flash alternately both the red and green LEDs in the LED indicator.
The following table indicates the available error codes:
When the camera detects a user correctable error, it sets the appropriate error code in an error
memory. If two or three different detectable errors have occurred, the camera will store the code for
each type of error that it has detected (the camera will store one occurrence of each code no matter
how many times it has detected the corresponding error).
You can use the following procedure to check the error codes:
Read the value of the LastError parameter. The LastError parameter will indicate the last error
code stored in the memory.
Execute the ClearLastError command to clear the last error code from the memory.
Continue reading and clearing the last error until the parameter indicates a No Error code.
Code Condition Meaning
0 No Error The camera has not detected any errors since the last time that the
error memory was cleared.
1 Overtrigger An overtrigger has occurred.
The user has applied a line start trigger to the camera when the
camera was not in a waiting for line start trigger condition.
2 User Set Load An error occurred when attempting to load a user set.
Typically, this means that the user set contains an invalid value.
Try loading a different user set.
3 Invalid Parameter A parameter is set out of range or in an otherwise invalid manner.
(Typically, this error only occurs when the user is setting parameters
via direct register access.)
4 Over Temperature The camera has stopped image acquisition due to overheating.
Provide adequate cooling to the camera.
5 Power Failure Power is erroneously supplied via the base Camera Link SDR
connector (PoCL) to a 6k, 8k, or 12k camera. Supply power via the 6-
pin connector.
Table 21: Error Codes
