Basler racer User Manual

AW00118508000 Specifications, Requirements, and Precautions
Basler racer Camera Link 17
1.7.4 Selecting the Optimum Lens Adapter
The camera’s scope of delivery does not include a lens adapter. It is needed to attach a lens to a
camera. You must order a lens adapter separately as an accessory.
The optimum choice of a lens mount adapter depends on the lens and on the resolution of the
camera model. The recommended combinations of lens adapters and camera models are indicated
in the following table:
1.7.5 Attaching a Lens Adapter
Use the four M2.5 setscrews supplied with the lens adapter to lock the lens adapter to the camera.
See Fig. 3 for information where to place the M2.5 setscrews.
Lens Adapter Camera Model
raL2048 raL4096 raL6144 raL8192 raL12288
C-mount
•
----
F-mount
•••••
M42 x 1.0
•••1) ••1)
M42 x 0.75
•••1) ••1)
M42 x 1.0 FBD 45.56
•••1) ••1)
M58
•••1) ••1)
1) To ensure coverage of the entire sensor, contact Basler technical support for assistance when choosing a lens.
Table 4: Recommended Lens Adapters Depending on Camera Model (
• = recommended, - = not recommended)
NOTICE
Screwing with excessive torque can damage the camera, lens adapter or setscrews.
When screwing in the supplied M2.5 setscrews, make sure to never exceed a torque of 0.4 Nm.
