AW00118508000 Specifications, Requirements, and Precautions
Basler racer Camera Link 3
1.4 General Specifications
Specification raL2048-80km raL4096-80km
Resolution 2048 pixels
max. 2040 pixels available with 1X10
tap geometry
4096 pixels
max. 4080 pixels available with 1X10
tap geometry
Sensor Type Awaiba DR-2k-7
Monochrome Linear CMOS
Awaiba DR-4k-7
Monochrome Linear CMOS
Effective Sensor Diagonal 14.34 mm 28.67 mm
Pixel Size 7 µm x 7 µm
Max Line Rate 80 kHz
Min Line Rate No minimum when a hardware trigger signal is used
100 Hz when a hardware trigger signal is not used
Mono/Color Mono
Sensor Bit Depth 12 bit
Data Output Type Camera Link base, medium or full configuration
Connectors One 6-pin Hirose micro-miniature receptacle
Two Camera Link 26-pin SDR connectors
(also known as Mini Camera Link connectors)
Camera Link Pixel Clock
Speed (Nominal)
32.5 MHz, 48 MHz, 65 MHz, 83.5 MHz (selectable; see Section 8.1 on
page 100 for the difference between nominal and actual values)
Camera Link Tap Geometry 1X, 1X2, 1X4, 1X8, 1X10
Pixel Formats Mono 8
Mono 10
Mono 12
Synchronization Via hardware trigger signal, via software trigger signal or free run
Exposure Time Control Programmable via the camera API
Camera Power Requirements PoCL (Power over Camera Link compliant)
or
+12 VDC (-10 %) to +24 VDC (+5 %), < 1 % ripple, supplied via the camera’s
6-pin connector.
Power Consumption
(typical, at 12 VDC)
3W 4W
I/O Lines 4 input lines (CC1 to CC4) and 1 output line (via Camera Link spare bit)
Table 1: General Specifications - 2k and 4k Mono Cameras
