AW00118508000 Physical Interface

Basler racer Camera Link 50

1. Use the LineSelector parameter to select CL Spare as the output line.

2. Set the value of the LineSource parameter to LineTriggerWait, ExposureActive, UserOutput, or

Off. This will select the source signal for the line.

You can set the LineSelector and the LineSource parameter values from within your application

software by using the pylon API. The following code snippet illustrates using the API to set the

parameter values:

// Select the line trigger wait signal for the CL Spare output line

camera.LineSelector.SetValue(LineSelector_CLSpare);

camera.LineSource.SetValue(LineSource_LineTriggerWait);

// Select the exposure active signal for the CL Spare output line

camera.LineSelector.SetValue(LineSelector_CLSpare);

camera.LineSource.SetValue(LineSource_ExposureActive);

// Select the CL Spare output line as a user output

camera.LineSelector.SetValue(LineSelector_CLSpare);

camera.LineSource.SetValue(LineSource_UserOutput);

// Disable the CL Spare output line

camera.LineSelector.SetValue(LineSelector_CLSpare);

camera.LineSource.SetValue(LineSource_Off);

For detailed information about using the pylon API, refer to the Basler pylon Programmer’s Guide

and API Reference.

You can also use the Basler pylon Viewer application to easily set the parameters.

For more information about the pylon API and the pylon Viewer, see Section 3.1 on page 26.

For more information about the Line Trigger Wait signal, see Section 6.3.3 on page 82.

For more information about the Exposure Active signal, see Section 6.3.1 on page 80.

For more information about working with outputs that have "user settable" as the signal source, see

Section 5.5.2.4 on page 51.

 Set the value of the Line Source CL Spare register to Line Trigger Wait, Exposure Active, or

User as desired.

For more information about direct register access, see Section 3.2 on page 28.

Default Output Line Source Signal Selections

By default, the camera’s Exposure Active signal is selected as the source signal for the CL Spare

output line.

To select the source signal for the output line using Basler pylon:

To select the source signal for the output line via direct register access:
