NE134
www.baumer.com
43
Technical data - mechanical design
Ambient temperature 0...+50 °C
Storing temperature -20...+70 °C
Relative humidity 80 % non-condensing
E-connection Plug-in screw terminals
Core cross-section 1.5 mm²
Protection DIN EN 60529 IP 65 face with seal
Operation / keypad Membrane with softkeys
Housing type Built-in housing
Dimensions W x H x L 48 x 48 x 100 mm
Installation depth 100 mm
Mounting Clip frame
Cutout dimensions 45 x 45 mm (+0.6)
Weight approx. 150 g (12...30 VDC / 85...265 VAC)
260 g (24/48 VAC)
Materials Housing: Makrolon 6485 (PC)
Keypad: Polyester
Technical data - trigger level
Comparator inputs Input circuit
Inputs PNP- / NPN-logic
Input level Programmable
Input level Low 0...2 VDC
Input level High 3...40 VDC
Input resistance 3 kΩ
Relay outputs Output circuit
Switching voltage max. 250 VAC / 110 VDC
Switching current max. 1 A
Switching capacity max. 150 VA / 30 W
Relay responding time 5 ms
Electronical outputs Output circuit,
Optocoupler short-circuit proof
Switching voltage max. 40 V
Switching current max 25 mA
