Line 35 Minimum pulse duration for control input 1
0 * 30 ms
1 100 µs
Line 36
Function control input 2 (contact 10)
0 PC - Main counter - Reset static
1 PC - Main counter - Reset edge-triggered
2 * PC - Main counter - Stop
3 Hold
4 Programming disabled
5 Keylock
6 Print
7 Main counter-outputs ON
8 Main counter-outputs OFF
9 External counting input for batch counter
Line 37
Function control input 3 (contact 11)
0 * tot - Totalizer - Reset static
1 tot - Totalizer - Reset edge-triggered
2 b - Batch counter - Reset static
3 b - Batch counter - Reset edge-triggered
4 Programming disabled
5 Keylock
6 Print
7 Main counter-outputs ON
8 Main counter-outputs OFF
9 External counting input for batch counter
Line 38
Take-over of presets P1, P2, SC
0 * Effective immediately
1 When resetting
Line 40
Output logic
0 * Both outputs as normally open
1 P1 normally closed, P2 normally open
2 P1 normally open, P2 normally closed
3 Both outputs as normally closed
Line 41
Output time P1
0.01 s Minimum signal duration
* 0.25 s
99.99 s Maximum signal duration
Latch = Latched signal (by pressing the - key)
Line 42
Output time P2
0.01 s Minimum signal duration
* 0.25 s
99.99 s Maximum signal duration
Latch = Latched signal (by pressing the
- key)
Line 50
Code setting
0 * Code not active
Max. 9999
