NE134
42 www.baumer.com
6 Technical data
Technical data - electrical ratings
Voltage supply 24/48 VAC ±10 % (50/60 Hz)
85...265 VAC (50/60 Hz)
12...30 VDC, 5 % RW
Power consumption 5 VA, 5 W
Sensor supply 24/48 VAC: 10...26 VDC / 60 mA
85...265 VAC: 24 VDC ±20 % / 100 mA
12...30 VDC: 9...28 VDC / 100 mA
Display LCD, 7-segment display,
2-lines, backlit
Number of digits 6-digits
8-digits - totalizer in 2 steps
Digit height 7 mm (count)
4 mm (preset)
Function Preset counter
Main counter with 2 presets
Batch counter with 1 preset
Totalizer
Scaling factor 0.0001...9999.99
Count modes Adding or subtracting
A-B (difference counting)
A+B total (parallel counting)
Up/Down
A 90° B phase evaluation
Counting frequency Main counter: 3 Hz, 25 Hz or 10 kHz
Batch counter: approx. 20 Hz
Operating modes Step preset, Trailing preset
Data memory >10 years in EEPROM
Reset Button, electric or automatic
Keylock Yes, electric (keylock)
Outputs electronic Optocoupler
Outputs relay
Normally open or closed, programmable
Output holding time 0.01...99.99 s
Interface RS485
Standard Protection class II
DIN EN 61010-1 Overvoltage category II
Pollution degree 2
Emitted interference DIN EN 61000-6-4
Interference immunity DIN EN 61000-6-2
Programmable Measuring units, sensor logic
parameters Operating modes
Scaling factor
Count mode
Approval UL approval / E63076
