5 Programming mode
Operation parameters are set on the programming mode. The pro-
gramming mode consists of 3 programming fields. Access is pro-
tected by a 4-digit code or via a control input.
Programming field 1
Here it is possible to select and modify all operation parameters. The
operation parameters that are disabled for the operator are also dis-
played.
Programming field 2
The individual operation parameters for operator access are disabled
or enabled here.
Programming field 3
All functions and values as well as interface parameters conditioned
by the machinery are programmed here.
Switch on programming
➜ Press key
and simultaneously.
„Code“ appears on the lower display.
No code number has yet been set at the factory, therefore it is pos-
sible to skip the code query by pushing . The code is set on pro-
gramming line 50. After a code has been set, it will only be possible
to switch to the programming mode by entering the correct code.
Enter code
Enter code via the keys
.
Press key to confirm.
The instrument switches from the operator to the programming level.
Wrong Code If a wrong code has been entered, „Error“ is displayed as long as
remains pushed. After 15 s the instrument switches automatical-
ly back to the operator level.
Correct code unknow If the correct code is not known, please return the counter to the
supplier or effect reset to factory setting.
Select programming lines Select the programming line needed via the keys
.
This function can also be reached by pushing .
The line number is displayed.
Modify operation Select the decade to be changed via the keys
.
parameters The selected decade blinks.
Enter the value by pushing the keys
.
Press key
.
Leave programming It is possible to shut down the programming at any time by pushing
and simultaneously.
Reset to factory setting Turn on instrument and press the keys
and simultaneously.
All values already programmed are set back to the factory setting.
„ClrPro“ briefly appears on the display.
