Example In the case of a length measurement by means of encoder and
cyclometer, where the circumference of the cyclometer measures
200 mm and the encoder supplies 500 pulses per revolution, the
measurement is to be displayed in mm.
The scaling factor is calculated as follows for this example:
Scaling factor =
Circumference
=
200
= 0.4000
Pulses 500
Read
Modify
➜ Press key
or .
The scaling factor SF is displayed.
➜ The lower display indicates „SF“.
➜ Enter the scaling factor via the keys .
The setting range from 0.0001 to 999.99 is attained by shifting the
decimal point. Select the decimal point via
and shift using .
➜ Press key .
By pushing or again, the current count is re-displayed.
