Technical data Syscompact 2000 M pro
/ 98 822-175-2
Surge voltage generator
Surge voltage ranges 0 – 8 kV, 0 – 16 kV
Surge energy 1024 J
Surge sequence 1 – 20 pulses/min, single surge
DC voltage 0 – 16 kV
Max. permissible output current in
DC voltage mode
Depends on the output voltage
Further information: Chapter Maximum permissible output current in DC
voltage mode (on page 15)
Display LCD with background lighting, screen resolution 160 x 80 pixels
User interface languages German, English, Polish, Portuguese, Russian
System
Power supply 100 – 240 V, 50/60 Hz
Max. power consumption 1500 VA
Ambient temperature (operation) -10°C to +50°C
Storage temperature -20°C to +60°C
Relative humidity 90%, Non-condensing
Height above sea level 2000 m
Degree of protection IP42
Dimensions (W x H x D) 680 x 1160 x 670 mm
(incl. carry handle and wheels)
Weight Approx. 90 kg
Safety and EMC CE compliant in accordance with Low Voltage Directive (2014/35/EU) and
EMC Directive (2014/30/EU)
