Baur Sys compact 2000 M pro - Procedure

Acoustic pin-pointing Syscompact 2000 M pro
74
/ 98 822-175-2
13.3.3 Procedure
On the system control panel
1. Press the MENU key on the display.
2. Select the SURGE MODE menu item and press the ENTER key.
3. Release the high voltage: Press the key for at least one second.
The system status changes to the Ready to switch on operating state. The red indicator
light flashes for approx. 6 seconds.
4. Switch on the high voltage by pressing the key within 6 seconds (while the red
indicator light flashes).
The system status changes to the In operation operating state. The set parameters appear
on the display.
5. Press the START key.
6. If required, use the arrow keys to change the surge sequence to a single surge or 10
pulses/min.
7. If required, use the ( / ) HV adjustment keys to change the surge voltage.
8. Connect the UL 30 universal receiver to the ground microphone.
9. Locate the cable fault with the universal receiver and the ground microphone.
If the breakdown noise can be heard clearly, use the acoustic signal to guide yourself
during the pin-pointing.
If the conditions are not suitable for a pure acoustic pin-pointing, you can also measure the
magnetic signal. Follow the instructions of the user manual for the BAUR UL 30 universal
receiver.
10. If you want to stop the acoustic pin-pointing, press the STOP key in the display.
11. Deactivate the high-voltage release by pressing the key.
DANGER
Dangerous voltage on the test object and other live machine parts. Danger to life,
risk of injury from high electric voltage.
12. Before touching test object, discharge, earth and short-circuit the same: at the connection
point and at the far end.
You may touch the plant parts that were under voltage only if they are visibly earthed and
short-circuited.
