Syscompact 2000 M pro Cable testing
822-175-2 51 / 98
11.3.3 Procedure
On the system control panel
1. Press the MENU key on the display.
2. In the display, select the CABLE TESTING menu item and press the ENTER key.
3. Release the high voltage: Press the key for at least one second.
The system status changes to the Ready to switch on operating state. The red indicator
light flashes for approx. 6 seconds.
4. Switch on the high voltage by pressing the key within 6 seconds (while the red
indicator light flashes).
The system status changes to the In operation operating state. The set parameters appear
on the display.
5. Press the START key.
The cable test starts.
6. If required and permitted, use the HV adjustment keys to change the ( / ) test voltage.
The test is stopped:
After the set test time
After a breakdown (in this case the breakdown voltage is displayed)
After 200 mA has been reached in burn mode
After the STOP key has been pressed
To continue with the cable testing, press the CONT. key.
7. If you do not wish to perform further tests, disable the high voltage release by pressing the
key.
DANGER
Dangerous voltage on the test object and other live machine parts. Danger to life,
risk of injury from high electric voltage.
8. Before touching test object, discharge, earth and short-circuit the same: at the connection
point and at the far end.
You may touch the plant parts that were under voltage only if they are visibly earthed and
short-circuited.
