Baxi ECOGEN 24/1.0 Installation & Servicing Instructions

Approximaterateis:±5%2.68m
3
/hrat20mbinletpressureforG20(NaturalGas)1.04m
3
/hrat37mbinletpressureforG31(PropaneGas),seeSection4.1.
NOTE:Forretrofitsystemsusingawiringcentreensurethatallexternalcontrolsarecallingforheat.

IMPORTANT:Thecombustionforthisappliancehasbeenchecked,adjustedandpresetatthefactoryforoperationonthegastypespecifiedontheappliancedataplate.
Nomeasurementofthecombustionisnecessary.Donotadjusttheair/gasratiovalve.
4.Havingchecked:
Thattheboilerhasbeeninstalledinaccordancewiththeseinstructions.
Theintegrityofthefluesystemandtheflueseals.
Theintegrityoftheboilercombustioncircuitandtherelevantseals.
Proceedtoputtheboilerintooperationasfollows:
5.Activatethechimneysweepfunctionbypressingandholdingtheeasymenuandmenubuttons(Fig.49a)whilstinthenormaloperationscreenuntilchimneysweep
functionoptionappears.PresstheSelectorButtontoswitchthechimneysweepfunctionon.
6.TheTHINKControllerwillshowChimneySweepFunctionon.ChimneySweepfunctionBurnerOutputAdjustappears.
PresstheSelectorButton.'Engineburnermin'willflash.
Usethewheeltoscrollthroughthesixoptions
a)Engineburnerminimum
b)Engineburnermaximum
c)Supplementaryburnerminimum
d)Supplementaryburnermaximum
e)EngineandSupplementaryburnersminimum
f)EngineandSupplementaryburnersmaximum
7.Choosethemaximumoperationf)andokyourchoice.Nomatterwhatthepreviousstateis,theburnerswillrestartbeforeachievingthedesiredrate.
Assoonasbothburnersarelitasshownbytheflamenumbers .
8.Withtheboileroperatinginthemaximumrateconditioncheckthattheoperational(working)gaspressureattheinletgaspressuretestpoint(Fig.50)isinaccordancewith
B.S.6798&B.S.6891.
9.Ensurethatthisinletpressurecanbeobtainedwithallothergasappliancesinthepropertyworking.
Fig.49a

STEP1 STEP2
STEP3 STEP4
page56
10.Carryouttheratemeasurement.Theburnerswillremainatmaximumrateunless:
a)Afaultconditionoccurstheburner/swillswitchoffdependingonthefault.
b)Theboilersetflowconditionisreached(seenote)theburnerswillswitchoff.
c)Thepowergeneratedreaches1kWtheengineburnerwillmodulatedown.
Forthisreasonthemeasurementneedstobecarriedoutonacoldsystemtobesureofobtaininganaccurateresult.

NOTE:Theboilersetflowtemperatureissetto90°toavoidinterruptionoftheratemeasurement.
11.Thechimneysweepfunctioncanbedeactivatedinthesamemannerasitisactivated.Itwilldeactivateautomaticallyafter20minutes,orintheeventofanfault.
12.Remember:TheengineburnerwillnotrestartuntiltheHeadTemperatureisbelow165°C.
12.0Completion
12.1Completion
1.InstructtheuserintheoperationoftheboilerandsystemincludingtheTHINKController,explainingtheoperationalsequence.
2.Setthecentralheatingandhotwatertemperaturecomfortlevelstotherequirementsoftheuser.
3.CarefullyreadandcompleteallsectionsoftheBenchmarkCommissioningChecklistattherearofthispublicationthatarerelevanttotheapplianceandinstallation.These
detailsmayberequiredintheeventofanywarrantywork.Thepublicationmustbehandedtotheuserforsafekeepingandeachsubsequentregularservicevisitrecorded.
4.Completethe'NoticeofInstallation'bookletandsubmitonthedayofcommissioningtotheDistributionNetworkOperator.
5.ForIE,itisnecessarytocompletea"DeclarationofConformity"toindicatecompliancewithI.S.813.AnexampleofthisisgiveninI.S.813"DomesticGas
Installations".ThisisinadditiontotheBenchmarkCommissioningChecklist.
6.HandovertheUsersOperating,InstallationandServicingInstructionsgivingadviceonthenecessityofregularservicing.
