Baxi ECOGEN 24/1.0 Installation & Servicing Instructions

ApplianceHydraulicResistanceChart
page10
5.0DimensionsandFixings
Dimensions
A 950mm
B 426mm
C 450mm
D 116mmØMin.
E 190mmAllowatleast250mmforassemblyandservicing
F 133mm
G 145mm
H 268mm
J 125mm
page11
6.0SystemDetails
6.1WaterCirculatingSystems
1.Theapplianceisonlysuitableforuseonsealedsystems.
2.IdeallyfitanewsealedheatingsystemtoBuildingRegulationspartL1(2010).Ifanexistingsealedsystemistobeusedthefollowingproceduremustbecompletedbefore
theEcogenisinstalled.

Baxi ECOGEN 24/1.0 Specifications

General

Brand	Baxi
Model	ECOGEN 24/1.0
Category	Boiler
Language	English
