Baxi ECOGEN 24/1.0 Installation & Servicing Instructions

CONCENTRICVERTICALFLUE
15.Oncethelengthoftheverticalconcentricextensionhasbeendeterminedmarkandcarefullycutofftheexcessmaterial.ThecutendMUSTbesquareandfreeofburrsto
ensurecorrectinsertionintotheboileradaptor.
16.Measure25mmfromtheendoftheflueextensionandapplyalengthoftapearoundtheouterduct(Fig.38).
17.Engagetheextensionintotheadaptoruptothisposition(Fig.39).Oncetheinstallationoftheflueiscompleteandallsupportbracketsaresecurelyinplaceremovethe
tape.
page36
10.0Electrical
10.1MakingTheElectricalConnections
Thisapplianceshallbeconnectedtoasuitablyprotectedelectricalsupplyi.e.,16Aseesection7.7.

NOTE:Ensureallcablesaresecuredusingthecableclampsprovided.
Whenaccessingtheappliancecontrolsarea,takecarenottoletthecontrolbox
dropdowninanuncontrolledmannerasthismaycausedamage.
1.Togainaccesstothecontrolstray/electricalwiringarea,removetheoutercasebyliftingofftheplasticfasciathatisheldonbytwomagnets.Undothetwoscrews
holdingtheoutercase,pullthebottomedgeforward,liftanddisengagefromthetopoftheappliance(Fig.40).
2.Slackenthefourscrewsfromthebottomcoverandremovethecover(Fig.40).
3.Removethetwoscrewsholdingthecontroltray.Pullthefrontofthecontroltrayforwardandloweritcarefully(Fig.41).DONOTallowthetraytofallinanuncontrolled
manner.
4.Ensureallcablesaresecuredusingthecableclampsprovided.
5.Ensurethatthelengthsoftheliveandneutralconductorsareshorterthattheearthconductor,sothatifthecableslipsinitsanchoragethecurrentcarryingconductors
becometautbeforetheearthconductor.
Fig.40&Fig.41
10.2Systeminstallationoptions.
1.Therearetwoinstallationoptionsavailable,IntelligentandRetro.Yplan,Splan,WplanandSPlanwithasecondheatingcircuitareallavailablebothwithIntelligent
andRetroinstallations.
IMPORTANT:Beforerunningtheapplianceensureparameter5700hasbeensetaccordingtothetypeofsysteminstalled.
Seesections10.4to10.11forsystemtypesandsection11.3.kforthechangeprocedure.
A)AnIntelligentsystemoperatestheEcogenwithroomsensors,anoptionalextraoutdoorsensor(anoutdoorsensorcanonlybeinstalledinconjunctionwitharoomsensorto
enableweathercompensation),aDHWtanksensororDHWtankthermostatandwillgivethehighestoverallefficiencywithincreasedelectricalpowergenerationandistherefore
therecommendedwaytoinstalltheappliance.
TheRemovableTHINKControllermustbeusedasaProgrammableRoomSensorforallintelligentinstallation.
