Baxi ECOGEN 24/1.0 Installation & Servicing Instructions

IFINANYDOUBTDONOTHANDLEORLIFTTHEBOILEROBTAINADVICEORASSISTANCEBEFOREPROCEEDING!!
page5
CONTENTS

1.0Introduction
2.0GeneralLayout
3.0ApplianceOperation
4.0TechnicalData
5.0DimensionsandFixings
6.0SystemDetails
7.0SiteRequirements
8.0FlueOptions
9.0Installation
10.0Electrical
11.0Commissioning
12.0Completion
13.0Servicing
14.0ChangingComponents
15.0CombustionCheck
16.0SchematicWiring
17.0FaultFinding
18.0EngineFaultFinding
19.0ShortPartsList
BenchmarkChecklist
page6
1.0Introduction
1.1Description
1.TheBaxiEcogen24/1.0isafullyautomaticgasfiredwallmountedcondensingheatonlyboilerwhichwillproduceupto1kWofelectricityforusebythehouseholder.Any
electricityexcesstorequirementsatthetimeofproductionwillbefedbackintothenationalgrid.Itisroomsealedandfanassisted.
2.Theboilerissettogiveamaximumoutputof:
24kW(Heat),1kW(Electric)
3.Theboilerissuitableforuseonlyonfullypumpedsealedsystems.
4.Theboilerdatabadgegivesdetailsofthemodel,serialnumberandGasCouncilnumberandissituatedontherearofthefacia(Fig.1).
5.Theboilermodelnameandserialnumberarealsoshownontheinformationlabelonthepanelbehindthefacia.Thisisforuserreference.
6.ModelsareavailableforuseonNaturalGas(G20)orPropaneGas(G31).
7.Theboilerisintendedtobeinstalledinresidential/commercial/lightindustrialE.M.C.environmentsonagovernedmeteredgassupplyonly.
8.OnCommissioningtheappliance,theDistributionNetworkOperator(DNO)mustbeinformedusingtheformprovided.
9.Theboilermustbeinstalledwithoneofthepurposedesignedfluessuchasthestandardhorizontaltelescopicfluekit,partno.5118069.
10.Allsystemsmustbethoroughlyflushedandtreatedwithinhibitor(seesection6.1&2).
Fig.1
1.2ContentsofPack
Thepackcontains:
Boiler
WallPlate
GasServiceCock
FixingScrews&WallPlugs
Template
LiteraturePack
