Baxi ECOGEN 24/1.0 Installation & Servicing Instructions

1.3OptionalExtras
1.FlueingkitsseeSection8.0
2.RemovableTHINKController
3.WallCradle&5LEDReceiverKit
4.OutsideSensor
5.CylinderSensor
page7
2.0GeneralLayout
2.1Layout

1 SupplementaryHeatExchanger
2 BurnerSupplementary
3 IgnitionElectrodes
4 FlameSensingElectrodes
5 SupplementaryGasValve
6 EngineBurner
7 EngineIgnitionElectrode
8 EngineFlameSensingElectrode
9 EngineGasValve
10 GasInlet
11 BoilerFlow
12 BoilerReturn
13 EngineAlternator
14 PCBControl/Cover
15 WaterFlowSensor
16 SafetyThermostats
17 FlowTemperatureSensor
18 CondensateTrap
19 ReturnTemperatureSensor
20 Fan
21 SpoolValveMotor
22 SpoolValve
23 Venturis
24 OvertravelSwitchesx2
25 CombustionTestPoint
26 AirFeedTestPoint
27 TransitBracket
28 EngineHeadThermocouples
29 ServiceResetButton
30 OvercurrentSwitch
31 Start/StopResistors
32 THINKController
33 Drain
34 IgnitionCoils
35 AmbientSensor
36 WallPlate
37 EMCMainsFilter
