Baxi ECOGEN 24/1.0 Installation & Servicing Instructions

Fig.14
Fig.15
Fig.15a
page23
8.0FlueOptions
8.1HorizontalFlueSystems
1.Thestandardflueissuitableonlyforhorizontalterminationapplications.
2.Allfittingsshouldbefullyengaged.Theapproximateengagementis40mm.Usethelubricationprovidedinthekittoaidassembly.
3.Forlongfluerunsallow5mmpermetreforexpansion.
4.Maximumpermissibleequivalentfluelengthsare:HorizontalConcentric(60/100)5metres
5.Anyadditional"inline"bendsinthefluesystemmustbetakenintoconsideration.
Theirequivalentlengthsare:
ConcentricPipes:  
(60/100) 135°bend 0.5metres
 93°bend 1.0metres
Theelbowsuppliedwiththestandardhorizontaltelescopicfluekitisnotincludedinanyequivalentlengthcalculations

NOTE:FluelengthismeasuredfrompointXtoYasshown.

IMPORTANT:Allfluesystemsmustbesecurelysupportedatleastonceeverymetre.
Suitablepipesupportsareavailableasaccessories.
