B)RetroinstallationsoperatetheEcogenwithaneworexistingexternalsystemwiringcentre.Thismeansthattheinstallerhastheoptiontoretainanexistingroomthermostat,
DHWthermostatandprogrammer.Anoutdoorsensorforweathercompensationcannotbeusedinthiscase.TheTHINKControllermustremainontheappliance(SeeSection
10.11).
page37
10.3CompleteWiringConfiguration
1.AllwiringexternaltotheappliancemustbeinaccordancewithI.E.E.BS7671requirementsforElectricalInstallations.
IMPORTANT:Beforerunningtheapplianceensureparameter5700hasbeensetaccordingtothetypeofsysteminstalled.
Seesections10.4to10.11forsystemtypesandsection11.3.kforthechangeprocedure.

*NOTE:AllFuses3.15
A
** PermanentLiveoncethe230Vsupplyisconnected
 *** Ensureallsystemwiringiscorrecttowiringregulations(BS7671)andfullytestedbeforeconnectiontoavoidanydamagetotheappliance
controls.
page38
10.4YPlanwithDHWcylindersensor
1.TheapplianceMUSThaveapermanentLive/Neutral/Earthconnection.Thepumpmustbeconnectedtotheapplianceasshown.
2.Setparameter5700to'2'foroneheatingcircuitseesection11.3.k.
NOTE:ItisnotpossibletooperateasecondheatingcircuitwithaYPlansystem.IntelligentInstallations
