Baxi ECOGEN 24/1.0 Installation & Servicing Instructions

Fig.80
page76
17.3ErrorCodes
BelowareshowntheerrorcodeswhichwillbedisplayedontheTHINKControllerifafaultoccursontheappliance.ErrorCodesshownonremoteinterfacesmaybecollective
codesrefertotheTHINKControllerfortheexacterrormessage.Morethanoneerrormaybepresentsothatsubsequenterrorcodeswillbeshownastheoriginalerrorisreset.
Theoccurrenceofanerrorcodewillpreventsomeoralloftheoperationsoftheappliance.
Errorcodesspecifictotherunningoftheenginewillnotpreventthesupplementaryburnerfromoperatingandvisaverse.
Therearethreelevelsoferrorcodewithassociatedresetproceduresasfollows:
1.Automaticreset(AR)Examplesaremainlytodowithtemperaturesensingbutalsoincludemonitoringofthemainssupply.Automaticresetonlyoccursifthefault
conditioniseliminated.
2.Userreset(UR)Anexamplewouldbetherestorationofthegassupplytoenableignition.
3.Servicereset(SR)ariseswhenaresetoftheconditionneedstobeaccompaniedbytheattendanceofaserviceengineer.
Therearetwospecialconditions:
1.Automaticresetafterpowerdown(ARP)anautomaticresetcanonlyoccuraftertheelectricalsupplyisinterrupted.Usuallythisimpliesdatacorruptionandisineffect
a'reboot'ofthePCB.
2.Norestartpossible(NRP)occursifthereiscorruptionofstoreddataforinstanceandimpliesthatthePCBwillhavetobereplaced.
page77
17.4ListofErrorCodes
Inthetablebelow:PCB=MainControlBoard,BCU=BurnerControlUnit.

Errorcode:
Display
Description Lockout/Reset
action
Fault
Section
Eng Sup
10:Outside
sensor
Faultoutsidetempsensor AR AR B
20:Boiler
sensor1
Faultboilerflowtempsensor AR AR C
40:Return
sensor1
Faultreturntempsensorboiler AR AR C
50:DHWtank
sensor
FaultDHW1sensor AR AR B
60:Room
sensor1
FaultroomtempsensorHC1 AR AR B
65:Room
sensor2
FaultroomtempsensorHC2 AR AR B
83:BSBshort
circuit
Boilersystembusshortcircuit AR AR B
84:BSB
address
collision
Morethen1roomunitsareassignedtothesameHCAssignoneofthemtoHC2or
assignQAA7xnotasroomunit
ARP ARP B
85:Radio
communication
Communicationtoradiodeviceinterrupted AR AR B
91:Dataloss
inEEPROM
FailureinClassBSW:IrreparabledatalossinEEPROM NRP NRP B
92:Device
electronics
error
RAMfailure,HBCprocessorregisterfailure,blockingchainundefined(toggling),safety
chaindiscrepancy.Reset:PressServiceResetwithin20secondsafterPowerup
NRP NRP B
95:Timeof
dayinvalid
Therealtimeclockunitdetectedcorruptedtimeofday.   B
96:MinorSW
failure
FailureinClassBSW:Stackoverfloworprogramsequencefailure AR AR B
97:SWorHW
failure
FailureinEGCSWwhichcausesnonvolatilelock. NRP NRP B
102:Clock
withoutbackup
Thechargingoftheclockbackupranout AR AR B
114:Shut'd
fluegas
Shutdownduetofluegasthermostatofsafetychain SR SR D
