Baxi Power HT Series User Manual

101
910.001.1 - EN
ISTRUCTIONS PERTAINING TO THE INSTALLER
Gas consumption at
15 °C 1013 mbar
Gas G20 - 2H - 20 mbar
POWER HT
1.850
POWER HT
1.1000
POWER HT
1.1200
POWER HT
1.1500
PCI MJ/m
3
34,02 34,02 34,02 34,02
Consumption at max. heat output m
3
/h 9,26 10,9 13,08 16,35
Consumption at min. heat output m
3
/h 3,50 3,89 4,23 4,39
Gas nozzle mm 11,5 12 11 11,5
CO
2
max. heat output % 8,7 8,7 8,7 8,7
CO
2
min. heat output % 8,6 8,6 8,4 8,4
Pout pressure at minimum power Pa - - -4 -5
Parameters H536-H613 (rpm) at maximum power 5100 5650 4650 6000
Parameters H541-H610 (pwm %) at maximum power 90 100 55 100
Parameter H612 (rpm) at minimum power 1900 2100 1600 1550
Parameter H609 (pwm) at minimum power 15 15 10 9,5
Parameter H611 (rpm) ignition load 3600 3600 2600 2900
Length of exhaust flue : 0 ÷ 10 m
Parameter H608 (pwm) ignition load 30 30 15 15
Length of exhaust flue : 10 ÷ 20 m
Parameter H608 (pwm) ignition load 40 40 20 20
Cascade solution with single clapet Ø 110/110
Parameters H536-H613 (rpm) at maximum power 5500 6000 — —
Parameter H612 (rpm) at minimum power
2200 2250 — —
Parameter H609 (pwm) at minimum power 16,5 16 — —
Parameter H608 (pwm) ignition load 40 40 — —
Table 2.1
Gas consumption at
15 °C 1013 mbar
Gas G31 - 3P - 37 mbar
POWER HT
1.850
POWER HT
1.1000
POWER HT
1.1200
POWER HT
1.1500
PCI MJ/Kg 46,34 46,34 46,34 46,34
Consumption at max. heat output Kg/h 6,77 7,97 9,56 11,95
Consumption at min. heat output Kg/h 2,57 2,86 3,10 3,22
Gas nozzle mm 7,8 7,8 7,8 7,8
CO
2
max. heat output % 10,2 10,2 10,2 10,2
CO
2
bei min Heizleistung % 9,3 9,8 10,2 10,2
Pout pressure at minimum power Pa - - -7 -8
Parameters H536-H613 (rpm) at maximum power 4600 5150 4300 5350
Parameters H541-H610 (pwm %) at maximum power 90 100 55 100
Parameter H612 (rpm) at minimum power 1900 1950 1450 1450
Parameter H609 (pwm) at minimum power 14,5 14,5 10 9,5
Parameter H611 (rpm) ignition load 4200 4200 2600 2900
Length of exhaust flue : 0 ÷ 10 m
Parameter H608 (pwm) ignition load 40 40 15 15
Length of exhaust flue : 10 ÷ 20 m
Parameter H608 (pwm) ignition load 50 50 20 20
Cascade solution with single clapet Ø 110/110
Parameters H536-H613 (rpm) at maximum power 5000 5500 — —
Parameter H612 (rpm) at minimum power 2200 2100 — —
Parameter H609 (pwm) at minimum power 16,5 16 — —
Parameter H608 (pwm) ignition load 50 50 — —
Table 2.2

Baxi Power HT Series Specifications

General

Model	Power HT Series
Type	Condensing Boiler
Installation	Wall-mounted
Heat Exchanger Material	Stainless Steel
Fuel Type	Natural Gas / LPG
Modulation Ratio	1:10
Ignition Type	Electronic
Safety Features	Flame Failure Protection
NOx Emissions	Low NOx
