62
910.001.1 - DE (AT)
ANLEITUNGEN FÜR DEN INSTALLATEUR
13. EINSTELLEN DER GASVENTILE
Die Modelle POWER HT 1.850 und 1.1000 haben ein einfaches Gasventil (Abbildung 12a).
Die Modelle POWER HT 1.1200 und 1.500 haben eine doppeltes Gasventil (Abbildung 12b).
0502_2108
Abbildung 12a
Pi: Anschluß Gasversorgung
P out: Anschluß für die OFFSET-
Messung
V: Stellschraube Gasdurchsatz
K: OFFSET-Stellschraube
0502_2109
Abbildung 12b
Gasmembran
Gasmembran
Venturi
Mischeinrichtung
Gasventil Sammler
