Baxi POWER HT+ Series Installation And Service Manual

P
Parameter
number
Parameter Description Factory set
ting
6020 F
Function extension
module 1
None
Multifunctional
: The functions that can be assigned to the inputs/
outputs
Temps / mode CH1
: Settings corresponding to the operator chapter
on "Heating Circuit 1"
Temps / mode CH2
: Settings corresponding to the operator chapter
on "Heating Circuit 2"
Temps / mode CH3
: Settings corresponding to the operator chapter
on "Heating Circuit 3"
Return temp controller
: Not used
Solar HW
: Settings corresponding to the operator chapter on "Ther
mal Solar"
Primary contr/system pump
: Not used
Temps /
mode CH2
6021 F
Function extension
module 2
See
Function extension module 1
Temps /
mode CH3
6022 F
Function extension
module 3
See
Function extension module 1
None
6024 F
Funct input EX21
module 1
None
Limit thermostat CH
None
6026 F
Funct input EX21
module 2
See
Funct input EX21 module 1
without
6028 F
Funct input EX21
module 3
See
Funct input EX21 module 1
without
6030 R
Relay output QX21
module 1
See
QX1 relay outlet
without
6031 R
Relay output QX22
module 1
See
QX1 relay outlet
without
6032 R
Relay output QX23
module 1
See
QX1 relay outlet
without
6033 R
Relay output QX21
module 2
See
QX1 relay outlet
without
6034 R
Relay output QX22
module 2
See
QX1 relay outlet
without
6035 R
Relay output QX23
module 2
See
QX1 relay outlet
without
6036 R
Relay output QX21
module 3
See
QX1 relay outlet
without
6037 R
Relay output QX22
module 3
See
QX1 relay outlet
without
6038 R
Relay output QX23
module 3
See
QX1 relay outlet
without
6040 S
Sensor input BX21
module 1
See
BX2 sensor inlet
without
6041 S
Sensor input BX22
module 1
See
BX2 sensor inlet
without
