P
Parameter
number
Parameter Description Factory set
ting
6042 S
Sensor input BX21
module 2
See
BX2 sensor inlet
without
6043 S
Sensor input BX22
module 2
See
BX2 sensor inlet
without
6044 S
Sensor input BX21
module 3
See
BX2 sensor inlet
without
6045 S
Sensor input BX22
module 3
See
BX2 sensor inlet
without
6046 F
Function input H2
module 1
See
the H5 inlet function
without
6047 C
Contact type H2
module 1
NC
NO
NO
6049 V
Voltage value 1 H2
module 1
Definition of parameters for collector specifications 0
6050 F
Funct value 1 H2
module 1
Definition of parameters for collector specifications 0
6051 V
Voltage value 2 H2
module 1
Definition of parameters for collector specifications 0
6052 F
Funct value 2 H2
module 1
Definition of parameters for collector specifications 0
6054 F
Function input H2
module 2
See
the H5 inlet function
without
6055 C
Contact type H2
module 2
NC
NO
NO
6057 V
Voltage value 1 H2
module 2
Definition of parameters for collector specifications 0
6058 F
Funct value 1 H2
module 2
Definition of parameters for collector specifications 0
6059 V
Voltage value 2 H2
module 2
Definition of parameters for collector specifications 0
6060 F
Funct value 2 H2
module 2
Definition of parameters for collector specifications 0
6062 F
Function input H2
module 3
See
the H5 inlet function
without
6063 C
Contact type H2
module 3
NC
NO
NO
6065 V
Voltage value 1 H2
module 3
Definition of parameters for collector specifications 0
6066 F
Funct value 1 H2
module 3
Definition of parameters for collector specifications 0
6067 V
Voltage value 2 H2
module 3
Definition of parameters for collector specifications 0
6068 F
Funct value 2 H2
module 3
Definition of parameters for collector specifications 0
6097 S
Type of collector sensor:
6100 R
The value of the outside temperature measurement can be offset by +/-
3
0°C
9 Settings
7609474 - v02 - 04092014 83
