Tab.3 Characteristics of the heating circuit
Unit
POWER HT+
1.130
POWER HT+
1.150
POWER HT+
1.200
POWER HT+
1.250
Water content (excluding expansion vessel) litre 10 11 13 15
Minimum operating pressure MPa (bar) 0.05 (0.5) 0.05 (0.5) 0.05 (0.5) 0.05 (0.5)
Maximum operating pressure (PMS) MPa (bar) 0.6 (6) 0.6 (6) 0.6 (6) 0.6 (6)
Maximum water temperature °C 85 85 85 85
Maximum operating temperature °C 80 80 90 90
Tab.4 Data on the gases and combustion gases
For gas flow rates at 15°C and
1013.25 hPA
Boiler speed Unit POWER HT
+ 1.130
POWER HT
+ 1.150
POWER HT
+ 1.200
POWER HT
+ 1.250
Minimum gas pressure (G20) mbar 17 17 17 17
Nominal pressure (G20) mbar 20 20 20 20
Maximum pressure (G20) mbar 25 25 25 25
Minimum gas pressure (G25) mbar 20 20 20 20
Nominal pressure (G25) mbar 25 25 25 25
Maximum pressure (G25) mbar 30 30 30 30
Minimum gas pressure (G25.1) mbar 18 18 18 18
Nominal pressure (G25.1) mbar 25 25 25 25
Maximum pressure (G25.1) mbar 33 33 33 33
Minimum gas pressure (G27) mbar 16 16 16 16
Nominal pressure (G27) mbar 20 20 20 20
Maximum pressure (G27) mbar 23 23 23 23
Minimum gas pressure (G31) mbar 25 25 25 25
Nominal pressure (G31) mbar 37 37 37 37
Maximum pressure (G31) mbar 57.5 57.5 57.5 57.5
Consumption of natural gas (G20) Minimum m³/h 2.6 3.0 3.4 4.2
Consumption of natural gas (G20) Maximum m³/h 13.1 15.1 20.2 25.4
Consumption of natural gas (G25) Minimum m³/h 3.1 3.5 3.9 4.9
Consumption of natural gas (G25) Maximum m³/h 15.2 17.6 23.5 29.5
Consumption of natural gas (G25.1) Minimum m³/h 3.0 3.5 3.9 4.9
Consumption of natural gas (G25.1) Maximum m³/h 15.2 17.6 23.5 29.5
Consumption of natural gas (G27) Minimum m³/h 3.2 3.7 4.1 5.2
Consumption of natural gas (G27) Maximum m³/h 16.0 18.5 24.7 31.0
Consumption of Propane (G31) Minimum kg/h 1.0 1.2 2.5 3.1
Consumption of Propane (G31) Maximum kg/h 5.1 5.9 14.8 18.6
NOx according to EN 15502–1 Class 5 mg/kWh 17 23 37 39
Flue gas mass flow rate (G20) Minimum kg/h 43.2 50.4 54 69
Flue gas mass flow rate (G20) Maximum kg/h 201.6 230.4 322 411
Maximum flue gas temperature Minimum °C 70 70 80 80
Tab.5 Electrical specifications
Unit POWER HT+
1.130
POWER HT+
1.150
POWER HT+
1.200
POWER HT+
1.250
Power supply voltage VAC 230 230 230 230
Maximum absorbed power - Full load W 187 283 242 369
Maximum absorbed power - Part load W 51 52 47 48
Maximum absorbed power - Stand-by W 3 3 3 3
3 Technical specifications
14 POWER HT + 7702630 - v02 - 11082018

Baxi POWER HT+ Series Specifications

General

Model	POWER HT+ Series
Category	Boiler
Installation Type	Wall-mounted
Heat Exchanger Material	Stainless Steel
Warranty	2 years
Fuel Type	Natural Gas
Control System	Integrated Control
Ignition Type	Electronic
