Baxi POWER HT+ Series - Page 41

Unpacking & initial preparation with slings
1. Remove the cardboard and the polystyrene packing.
2. Remove the protective plastic.
3. Remove the front panel by pulling firmly on the slots provided.
Fig.45
MW-2000765-2
1
2
Fig.46
MW-2000766-2
3
5 Before installation
7702630 - v02 - 11082018 POWER HT + 41
