Pre-setting selected Hours programmed
Time setting 1 6:00 to 23:00
Time setting 2 06:00...08:00 – 17:00...23:00
Time setting 3 06:00...08:00 – 11:00...13:00 – 17:00...23:00
Default time ranges
Tab.61 Time ranges according to the groups of days selected
Program line 514 (heating), 574 (domestic hot water)
Groups of days Pre-set programs
On 1 - Off 1 On 2 - Off 2 On 3 - Off 3
Mon-Sun 06:00 - 08:00 11:00 - 13:00 17:00 - 23:00
Mon-Fri 06:00 - 08:00 17:00 - 23:00
Sat-Sun 06:00 - 23:00
Tab.62 Time ranges according to the days selected
Program line 501, 502, 503, 504, 505, 506 (heating) - 561, 562, 563, 564, 565, 566 (domestic hot water)
Single days Pre-set programs
On 1 - Off 1 On 2 - Off 2 On 3 - Off 3
Monday-Tuesday-Wed
nesday-Thursday-Friday-
Saturday-Sunday
06:00 - 08:00 11:00 - 13:00 17:00 - 23:00
Selecting a Timer Program
1. Select a heating circuit.
2. Press the
key to access the parameters.
3. Select the Time central heating CH1 menu by turning the button.
Important
For heating circuits 2 and 3, select the parameters Time central
heating CH2
or Time setting 3/CHP.
For the domestic hot water circuit, select the parameter Time
hot water.
4. Confirm the menu selection by pressing the button.
The parameter Select days (500, 520, 540 or 560) appears.
Fig.122
