BA series pumps
1401 Pump unit with diesel drive
8.7
WARNING
Connection of the external fuel tank must be performed by the user. The user is
responsible for making the connection and installing the necessary safety
measures.
Check for fuel leaks after making the connections.
WARNING
Make sure that if a leak should occur no fuel can enter the pump unit.
WARNING
Leakage of fuel can be extremely harmful to the environment. Do everything
necessary to prevent fuel leakage.
Note
After the lines have been connected, secure them inside the housing.
Take measures to prevent them from rubbing against sharp parts.
Selection handle (optional)
– Set the handle (2) to ‘EXTERN’ to use fuel from the
external fuel tank.
– Set the handle (2) to ‘INTERN’ to use fuel from the
internal fuel tank.
Note
If the handle is in the ‘INTERN’ position, the external
tank does not necessarily have to be connected.
Priming the fuel system
Prime the fuel system before starting the engine for the first time, after the fuel tank has been drained
completely or after replacement of the fuel filter(s).
1. Set the fuel handle (2) to the desired position (INTERN or EXTERN).
2. Make sure there is sufficient fuel in the selected tank.
3. Visually inspect the fuel lines for routing and leakage.
4. Open the bleeder screw (3).
