BBK DK1410SI - Page 119

MATERIAL
CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0960020
CMETAL OXIDE FILM
RESISTORSTAL OSCILLATOR
27.00MHz 49-S X201
1940140 CABLE SOCKET
14P 1.0mm DUAL RANK STRAIGHT
INSERT
XS207
1940065 SOCKET 13P 2.0mm XS206
1940005 SOCKET 6P 2.0mm XS303,XS201
1940024 SOCKET 5P 2.0mm XS302
1940004 SOCKET 5P 2.5mm XS203
0090001 SMD RESISTOR 1/16W 0O±5% 0603
L305,L309,L310,L312,R213,R214,R217,R2
30,R231,R243,R318
0090272 SMD RESISTOR 1/16W 1O±5% 0603 R304~R307,R321
0090106 SMD RESISTOR 1/16W 4.7O±5% 0603 R301,R302
0090003 SMD RESISTOR 1/16W 10O±5% 0603 R303
0090005 SMD RESISTOR 1/16W 33O±5% 0603 R234~R237,R2004~R2009,R2024
0090006 SMD RESISTOR 1/16W 75O±5% 0603 R223
0090016 SMD RESISTOR 1/16W 1.5K±5% 0603 R323,R324
0090009 SMD RESISTOR 1/16W 330O±5% 0603 R340,R377,R381
0090249 SMD RESISTOR 1/16W 510O±5% 0603 R228,R325,R327
0090012 SMD RESISTOR 1/16W 560O±5% 0603 R206
0090014 SMD RESISTOR 1/16W 1K±5% 0603 R232,R233,R2025
0090019 SMD RESISTOR 1/16W 4.7K±5% 0603 R238~R241,R2010,R2003,R2000
0090023 SMD RESISTOR 1/16W 10K±5% 0603
R201,R309,R311,R313,R314,R329,R330,R
339,R364,R2002
0090024 SMD RESISTOR 1/16W 15K±5% 0603 R202,R211
1940094 CABLE SOCKET
24P 0.5mm SMD SUBMIT MEET WITH
CLASP
XS301
0090188 SMD RESISTOR 1/16W 18K±5% 0603 R203
0090025 SMD RESISTOR 1/16W 20K±5% 0603 R204,R312,R315,R316
0090029 SMD RESISTOR 1/16W 47K±5% 0603 R2001,R2023
0090030 SMD RESISTOR 1/16W 56K±5% 0603 R2011
0090197 SMD RESISTOR 1/16W 150K±5% 0603 R319,R320
0090211 SMD RESISTOR 1/16W 680K±5% 0603 R317,R322
0090212 SMD RESISTOR 1/16W 750K±5% 0603 R209
0090609 PRECISION SMD RESISTOR 1/16W 100O±1% 0603 R245
0090626 PRECISION SMD RESISTOR 1/16W 200O±1% 0603 R244
DECODE BOARD 2DK1410S-0 1.2Ver2.1
DVD HOME THEATER DK1410SI(RU)
