BBK DK1410SI - Page 121

MATERIAL
CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0780040 SMD TRIODE 3904(100-300) SOT-23 Q305
0780193 SMD TRIODE 2SK3018 Q303,Q304
0780115 SMD TRIODE 2SB1132 Q301,Q302
0882756 IC HEF4094BT SOP U213
0880165 IC 74HCU04D SOP
U205 ⑤
0880322 IC MM74HCU04M SOP
U205 ⑤
0880513 IC HCU04 SOP
U205 ⑤
0882262 IC K4S641632H-TC60 TSOP
U208 ⑥
0882559 IC HY57V641620ET-7 TSOP
U208 ⑥
0881182 IC LM1117MP-ADJ SOT-223
U206 ⑦
0881969 IC IP1117-ADJ SOT-223
U206 ⑦
0882461 IC AZ1117H-ADJ SOT-223
U206 ⑦
0881031 IC 24C02N SOP U202
0882643 IC MT1389FE/E(E) QFP U201
0881378 IC BA5954FP HSOP U301
1633019 PCB 2DK1410S-0
00003759 CARBON FILM RESISTOR 1/4W2.2O±5% BELT R326
02604379 CD CD11 16V10U±20%5×11C5 BELT TC204~TC206,TC212,TC217
02600029 CD CD11 16V47U±20%5×11 C5 BELT TC219,TC302,TC303,TC305,TC306,TC215
02601889 CD CD11 16V100U±20%6×12 C5 BELT TC207,TC211,TC216,TC304,TC320
02601819 CD CD11 16V220U±20%6×12 C5 BELT
TC208,TC209,TC210,TC213,TC214,TC218
,TC301
03900579
MAGNETIC BEADS
INDUCTOR
RH354708 BELT L213~L216,L218,l219
03904299 INDUCTOR
330UH±10％ 0410 BELT
L204
0310222 SMD CAPACITOR 25V 104±20% X7R 0603 C3 ,C5
0310191 SMD CAPACITOR 50V 30P±5% NPO 0603 C1, C2
0090029 SMD RESISTOR 1/16W 47K±5% 0603 R2
0090233 SMD RESISTOR 1/16W 4.7MO±5% 0603 R3, R4
0090002 SMD RESISTOR 1/16W 2.2O ±5% 0603 R5
0700007 SMD DIODE 1N4148 VD2
0970008 CERAMIC RESONATOR 2.0MHz G1
DVD HOME THEATER DK1410SI(RU)
REMOTE CONEROL 5471746
