I) Alternate digital video YUV output 0
II) GPIO
154 ASDATA0
YUV2
GPO
InOut 4mA,
PD,SMT
8) Audio serial data 0 (Front-Left/Front-Right)
9) Trap value in power-on reset:
I) 1: manufactory test mode
II) 0: normal operation
10) While internal audio DAC used:
I) Digital video YUV output 2
II) GPO
155 ASDATA1
YUV4
GPO
InOut 4mA,
PD,SMT
11) Audio serial data 1 (Left-Surround/Right-Surround)
12) Trap value in power-on reset:
I) 1: manufactory test mode
II) 0: normal operation
13) While only 2 channels output:
I) Digital video YUV output 4
II) GPO
156 ASDATA2
YUV5
GPO
InOut 4mA,
PD,SMT
14) Audio serial data 2 (Center/LFE)
15) Trap value in power-on reset:
I) 1: manufactory test mode
II) 0: normal operation
16) While only 2 channels output:
I) Digital video YUV output 5 II) GPO
157 ASDATA3
YUV6
GPIO
InOut 4mA,
PD,SMT
17) Audio serial data 3 (Center-back/
Center-left-back/Center-right-back, in 6.1 or 7.1 mode)
18) While only 2 channels output:
I) Digital video YUV output 6
II) GPIO
158 MC_DATA
INT2#
YUV0
InOut 2mA,
19) Microphone serial input
20) While not support Microphone:
I) Microcontroller external interrupt 2
II) Digital video YUV output 0
III) GPIO
159 SPDIF
Output
4~16mA,
SR: ON/OFF
S/PDIF output
172 AADVSS Ground Ground pin for 2ch audio ADC circuitry
