User’s Guide56
Changing the sheath filter
Introduction This topic describes how to change the sheath filter. The sheath
filter is connected in-line with the sheath line. It filters the sheath
fluid as it comes from the sheath container.
When to change
th
e sheath filter
We recommend changing the sheath filter assembly every
six months. Increased debris appearing in an FSC vs SSC plot can
i
ndicate that the sheath filter needs to be replaced. See Supplies and
consumables (page 121) for ordering information.
Sheath filter
components
The following illustration shows the s
heath filter components.
Filter base
Quick-disconnect
Sheath line
Vent fitting
Vent line
