Page 5-44 MedPlus TotalAlert® Alarm Network Operation and Maintenance Manual (205728)
Connecting Cables
Chapter 5: Parts List
Connecting Cables
Figure 5-18. Connecting Cables
Table 5-16. Connecting Cables
Item Number Part Number Quantity Description
1 20551801 1 Ribbon cable assembly, 10 conductor, 10"
2 20551901 1 Ribbon cable assembly, 26 conductor, 12"
3 20551902 1 Ribbon cable assembly, 26 conductor, 16"
4 205997 1 Flat cable snap-its
