Fault indication
Normal/master mode
The transmitter can be operated in two modes:
• Normal mode (normal operation) The commands that are issued apply to
all the receivers of a channel.
• Master mode (Setting mode for all B‑Tronic products) The commands is-
sued apply exclusively to one selected receiver of a channel.
The normal mode is factory set.
Activating master mode
Press the master button until the changeover button flashes
green once per second. This flashing will continue as long as you remain in
master mode.
By pressing the master button again, the programmed drive is selected, or the
programmed drives are selected in sequence.
The selected drive confirms by "clicking".
You can now make the various settings that are only available in master mode.
When all the desired settings have been made at this drive, you can press the
master button again to select the next driver for programming.
Leaving master mode
There are two ways to leave master mode:
1. Press the changeover button.
2. Master mode is automatically closed once 2 minutes have gone by
without a button being pushed
Programming the first transmitter
1) Programming transmitters
a) Putting the receiver into programming mode
Follow the Assembly and Operating Instructions for the re-
ceiver.
8
