GB Sound speed controller SFR-1
06.02.2019 BEIER-Electronic 15
General remarks for wiring
Always use cables with a core diameter of at least 1,5 mm² for connecting the power
supply and the motor. For all other connections, such as lights you can use smaller
cables such as 0.25 mm².
Unfortunately motors are often strong interference sources, which could disturb other
electronic modules in your model. Therefore all motors should be absolutely
interference-suppressed!
It is important to pay attention to „clean" wire routing. Always use short wires and
avoid any unnecessary loops. The supply voltage wires of the speed controller
should be connected to the driving-battery as direct as possible.
