Page #157 background image
BHT-206L4-MM-1
5-00-00
25 FEB 2011 Rev. 13 Page 121
ECCN EAR99
SCHEDULED INSPECTIONS
5-41. 2250 HOURS OR 60 MONTHS OF COMPONENT OPERATION
DATA REFERENCE INSPECTION TASK DESCRIPTION
INITIAL
MECH OTHER
DATE: __________________W.O. _____________________
FACILITY: __________________________________________
HELICOPTER S/N: ___________________________________
REGISTRY NO.: _____________________________________
TOTAL TIME:_______________________________________
SIGNATURE:________________________________________
TRANSMISSION
NOTE
This inspection is applicable to transmission
assemblies 206-040-004-115 and subsequent that
have been operating with DOD-PRF-85734 oil since
new or since last overhaul (TB 206L-04-213).
If the transmission has been operated with
MIL-PRF-7808 oil, the 1500 Hours Of Component
Operation scheduled inspection applies.
Chapter 63 1. If installed on the helicopter, remove the transmission
assembly.
2. Remove the mast and swashplate assembly from the
transmission assembly.
3. Inspect oil filter for debris and metal contamination.
BHT-206L-CR&O 4. Remove the transmission top case, the planetary
assembly, and the sun gear.
5. Visually examine all removed components for condition.
6. Insert a mirror between the spiral bevel gear edge and the
lower case and use a bright light to examine the spiral bevel
gear, input pinion gears, and surrounding areas for condition.
