BHT-206L4-MM-1 TC APPROVED
4-00-00
Page 6 Rev. 23 25 JUN 2019
Export Classification C, ECCN EAR99
WARNING
SOME PARTS ARE INSTALLED AS
ORIGINAL EQUIPMENT ON BOTH
MILITARY AND COMMERCIAL
HELICOPTERS AND MAY HAVE A
LOWER AIRWORTHINESS LIFE AND/OR
OVERHAUL SCHEDULE WHEN USED
ON A MILITARY HELICOPTER. IN
ADDITION, CIRCUMSTANCES
SURROUNDING THEIR USE MAY CALL
FOR OPERATION OF THE MILITARY
HELICOPTER OUTSIDE OF THE
APPROVED COMMERCIAL FLIGHT
ENVELOPE. CONSEQUENTLY, PARTS
THAT HAVE BEEN USED ON MILITARY
HELICOPTERS SHOULD NOT BE USED
ON COMMERCIAL HELICOPTERS.
CAUTION
AIRWORTHINESS LIFE OF SOME KIT
COMPONENTS IS NOT COVERED IN
THIS SCHEDULE. REFER TO
APPLICABLE SERVICE INSTRUCTION
(SI) OR MAINTENANCE MANUAL
SUPPLEMENT (MMS) FOR KIT
COMPONENT SCHEDULES.
NOTE
The retirement life given, or the failure to
give a retirement life to a component, does
not constitute a warranty of any kind. The
only warranty applicable to the helicopter or
any component is the warranty included in
the Purchase Agreement for the helicopter
or the component.
The airworthiness lives given to the components and
assemblies are determined by experience, tests, and
the judgment of Bell Helicopter engineers. The lives
cannot be changed without the approval of the
Minister of Transport Canada.
Prior to disposing of unsalvageable helicopter parts
and materials, caution should be exercised to ensure
that the parts and material are disposed of in a manner
that does not allow them to be returned for service.
Refer to FAA Advisory Circular 21-38 for guidance on
the disposal of unsalvageable aircraft parts and
materials.
Table 4-1. Airworthiness Limitations Schedule
COMPONENT
PART NUMBER
AIRWORTHINESS LIFE
MAIN ROTOR HUB AND BLADES
Main Rotor Trunnion 206-011-120-103/-105 24,000 RIN
Strap Retention Pin 206-011-125-001 1200 hours
Main Rotor Grip 206-011-132-113 4800 hours
Tension Torsion Strap 206-011-147-007 1200 hours/24 months
Strap Retention Fitting 206-011-150-105 2400 hours
Tension Torsion Strap 206-011-154-103/-107 1200 hours/24 months
Latch Bolt 206-011-260-101 1200 hours
Main Rotor Blade 206-015-001-001/-103/-105/
-107/-109/-111/-113/115/-117/
-119/-121
4000 hours
1
21
22
11
11
17
31
36
