BHT-206L4-MM-1
5-00-00
Page 34 Rev. 13 25 FEB 2011
ECCN EAR99
Pay particular attention to the upper left side tailboom
quadrant.
b. Cracks.
c. Deformation.
Pay particular attention to the rivets attaching the tail
rotor gearbox support to the tailboom.
BHT-206-SRM d. Loose rivets. Replace as required.
Chapter 53 e. Chafing.
f. Waviness.
5. Examine drive shaft cover clips for condition and security.
Inspect all clip edges for integrity of sealant. Reseal as required.
6. As applicable to tailbooms modified in accordance with
ASB 206L-99-115, inspect doubler around stabilizer of left side
for integrity of sealant. Reseal as required.
7. Examine horizontal stabilizer for condition and security.
Verify security of all attachment bolts.
8. Examine elevators for condition, security, and side play.
9. Examine auxiliary finlets for condition and security.
10. Examine vertical fin assembly for condition and security.
11. Inspect the vertical fin attachment support for condition and
damage. Pay particular attention to the vertical fin attachment
points.
12. Examine for open tailboom drains on lower tailboom skin
and clear any obstructions.
13. Inspect antennas for damage and security.
5-18. 100-HOUR AIRFRAME PROGRESSIVE INSPECTION — EVENT NO. 3 (CONT)
DATA REFERENCE INSPECTION TASK DESCRIPTION
INITIAL
MECH OTHER
