BHT-206L4-MM-1
5-00-00
Page 180 Rev. 18 7 JUN 2013 Export Classification C, ECCN EAR99
BHT-206L-CR&O (1) If indications of arcing or burning are present or
bearings do not rotate smoothly, overhaul swashplate assembly.
Replace the affected hardware.
BHT-206L-CR&O (2) If no indications are found, reassemble the
swashplate assembly and return to service.
h. Inspect tailboom, horizontal stabilizer, auxiliary fins, and
vertical fin for evidence of arcing, burning, or debonding paying
particular attention to area around the mounting points for the
tail rotor driveshaft hangers and tail rotor gearbox.
Rolls-Royce 250-C30
Series Operation and
Maintenance Manual,
14W2
i. Inspect power plant assembly.
5-56. LIGHTNING STRIKE (CONT)
DATA REFERENCE INSPECTION TASK DESCRIPTION
INITIAL
MECH OTHER
