BHT-206L4-MM-1
5-00-00
ECCN EAR99
Figure 5-1. Maintenance Zones
206L4_MM_05_0001
ZONE 1
ZONE 3
ZONE 7
ZONE 10
ZONE 8
ZONE 9
ZONE 4
ZONE 5
ZONE 6
ZONE 2
Zone 1
Zone 2
Zone 3
Zone 4
Zone 5
Zone 6
Zone 7
Zone 8
Zone 9
Zone 10
- Main rotor hub and blade assembly
- Tail rotor hub and blade assembly
- Forward top deck
- Power plant
- Aft top deck
- Tailboom
- Cabin interior
- Foward fuselage
- Aft fuselage
- Landing gear
25 FEB 2011 Rev. 13 Page 15/16
