Bell 429 - Page 166

BHT-429-MPI
Table1.ConditionalInspections-CompressorStallorSurge(continued)
INITIAL
DATAREFERENCEINSPECTIONTASKDESCRIPTION
MECHOTHER
b.AttachaTHISCOMPONENTWASREMOVEDFROMSERVICE
BECAUSEOFACOMPRESSORSTALLORSURGEtagonthe
transmissionassemblyortailrotorgearbox,asapplicable.
c.Sendthetransmissionassemblyortailrotorgearboxtoanapproved
repairfacilitytodisassemble,clean,anddoadetailedinspectionofthe
transmissionassemblyortailrotorgearbox,asapplicable.
d.Iftherearenounwantedparticles,thetransmissionassemblyandthe
tailrotorgearboxareserviceable.
3.IfthecompressorstallorsurgeoccurredontheengineNo.2
(right-handengine),dothefollowing:
a.Onthetransmissionassembly,removetherequiredinspectionplug(s).
b.Examinethegearteethofthefollowingpartsforscoringandother
mechanicaldamagewithaborescope:
•Spurgear(right-handside)
•Idlergear
•T ailrotordrivegear
•Spiralbevelpinion(right-handside)
4.IfthecompressorstallorsurgeoccurredontheengineNo.1
(left-handengine),dothefollowing:
a.Onthetransmissionassembly,removetherequiredinspectionplug(s).
b.Examinethegearteethofthespiralbevelpinion(left-handside)for
scoringandothermechanicaldamagewithaborescope.
5.Ifdamageisfoundongearsofthetransmissionassembly,dothe
following:
a.Removethetransmissionassembly.
b.AttachaTHISCOMPONENTWASREMOVEDFROMSERVICE
BECAUSEOFACOMPRESSORSTALLORSURGEtagonthe
transmissionassembly.
c.Sendthetransmissionassemblytoanapprovedrepairfacilityto
disassembly,cleananddoadetailedinspection.
6.Ifnodamageisfoundonthegears,thetransmissionassemblyis
serviceable.
429-MM,Chapter65TAILROTORDRIVESYSTEM
1.Onthetailrotorgearbox,removetheinspectionplug.
2.Examinethecontactpatternsofthepiniongearwithastronglight.
Ifthegearcontactpatternsshowsignsofscufng,scoring,orother
mechanicaldamage,dothefollowing:
a.Removethetailrotorgearbox.
b.AttachaTHISCOMPONENTWASREMOVEDFROMSERVICE
BECAUSEOFACOMPRESSORSTALLORSURGEtagonthetail
rotorgearbox.
c.Sendthetailrotorgearboxtoanapprovedrepairfacilityforinspection
andrestorationofthetailrotorgearbox.
3.Doatorquecheckofthetailrotorgearboxattachmenthardware.
4.Examineallthecomponentsofthetailrotordriveshaftassemblyfor
conditionandsecurityofattachment.
a.Ifanydamageisfound,repairorreplacethedamagedpart(s)as
required.
429-A-05-50-00-07A-284A-AApplicableto:ALL
Page2Issue1-10JAN2019
ECCNEAR99
